Plan accessible commercial entry around door operation, reader and intercom placement, automatic operators, and the needs of people using each controlled opening.
Electronic access control can improve security and accountability, but the equipment controlling an opening should not create unnecessary barriers for people with disabilities.
Northeast Remote Surveillance and Alarm, LLC (NERSA) designs and installs commercial and industrial access control. We review reader placement, door operation, entry hardware and accessible routes. Planning also covers egress, automatic operators and applicable project requirements.
NERSA supports scalable applications ranging from a single controlled entrance for a small business through multi-door commercial properties, industrial facilities, campuses and enterprise environments.
For broader code-conscious security planning, visit Code and Compliance for Commercial Security Systems.
Accessibility at an Electronic Access-Controlled Opening
Electronic access control affects more than whether a credential is accepted.
The complete opening may involve:
- Card reader
- Keypad
- Mobile credential reader
- Intercom or call station
- Electric locking hardware
- Door closer
- Automatic door operator
- Push plate or actuator
- Request-to-exit equipment
- Door and frame
- Pedestrian gate
- Accessible path of travel
Each component should be considered as part of the way an authorized person actually approaches, operates and passes through the opening.
An access-control system can work electronically and still be difficult to use. A reader may be hard to reach, an actuator blocked or a door difficult to operate. Equipment must also be considered in relation to the intended accessible route.
Reader, Keypad and Intercom Placement
Credential devices need to be placed where authorized users can reasonably approach and operate them.
This may include:
- Card and fob readers
- Keypads
- Mobile credential readers
- Intercom stations
- Visitor call buttons
- Entry-release controls
Planning should consider the mounting location, approach to the device, nearby walls or obstructions, the surrounding door hardware and the space available for a person to use the device.
A reader should not be positioned solely around the easiest wiring route.
For example, equipment mounted behind a bollard, landscaping element, structural obstruction or poorly positioned door may be technically functional while being difficult for some users to reach.
The access-control device should be considered together with the physical approach to the opening.
Controlled Doors and Accessible Operation
The access-control system should work with the door rather than making the opening unnecessarily difficult to use.
A controlled commercial door may include:
- Electric strike
- Electrified trim
- Magnetic lock
- Exit hardware
- Door closer
- Door-position contact
- Request-to-exit equipment
- Automatic operator
- Access-control reader
The physical condition and operation of the door matter.
An opening that binds, closes improperly, has unsuitable hardware or requires excessive effort to operate can remain problematic even when the electronic access-control equipment works correctly.
Access-control planning should therefore consider both security on entry and practical use of the complete opening.
For complete access-control system planning, visit Commercial & Industrial Access Control Systems.
Automatic Door Operators and Assisted Entry
Some commercial openings use automatic operators or other assisted-entry equipment to support accessible use.
These applications may be encountered at:
- Public entrances
- Offices
- Healthcare properties
- Schools
- Municipal facilities
- Multi-tenant buildings
- Commercial campuses
- Other high-use entrances
When an automatic operator is used at an access-controlled door, the operator, credential reader, push plate, locking hardware and door sequence need to work together.
The opening should not be treated as a collection of unrelated devices.
For example, credential authorization, unlocking, automatic opening, closing and secure relatching may all need to occur in the correct sequence.
Planning the entire opening together can help avoid situations where one piece of equipment interferes with another.
Accessible Egress and Life-Safety Coordination
Electronic entry control must not improperly interfere with required exit operation.
Electrified locks, magnetic locks, strikes, exit devices, request-to-exit equipment and automatic operators may all affect how a controlled opening functions.
Depending on the opening and system design, planning may require consideration of:
- Normal exit operation
- Emergency egress
- Exit hardware
- Required locking behavior
- Fire alarm interfaces
- Door closing and latching
- Automatic operators
- Accessible routes
- Other life-safety requirements
The appropriate arrangement depends on the building, opening and applicable requirements.
Where an access-controlled opening involves inspection-sensitive life-safety conditions, the security design should be coordinated with the appropriate building owner, design professional, door-hardware provider, fire-alarm provider, contractor or authority having jurisdiction as required.
For additional egress-focused planning, visit NFPA 101 Life Safety Code and Access-Control Egress Compliance.
Exterior Readers, Gates and Accessible Routes
Accessibility considerations do not stop at the building entrance.
Commercial properties may also have controlled:
- Pedestrian gates
- Employee entrances
- Visitor entrances
- Parking-area approaches
- Exterior credential readers
- Intercom stations
- Building approach routes
When a controlled gate or exterior opening is located along an accessible route, the location and usability of the access-control equipment should be considered as part of the complete path.
A credential reader that can only be reached from an awkward position or an intercom located away from the usable approach can create problems even when the gate itself operates correctly.
Security planning should preserve the intended movement through the property while still controlling authorized entry.
Small Business Through Enterprise Accessibility Planning
Accessibility-conscious access control applies at every scale.
A small business may have one primary entrance where a reader, locking device and automatic operator need to work together correctly.
A larger commercial facility may have multiple employee and public entrances with different hardware and operating requirements.
Healthcare, educational, municipal and industrial properties may have several accessible routes, controlled interior areas and multiple user groups.
Enterprise and campus environments may require consistent accessibility and access-control planning across many buildings or locations.
The number of doors changes, but the basic principle does not:
The security system should support authorized entry without unnecessarily interfering with accessible building use.
Existing Access-Control Systems
Accessibility concerns may also appear in systems that are already installed.
Examples can include:
- Reader positioned poorly for the intended approach
- New automatic operator added to an older controlled door
- Door hardware changed without coordinating access-control operation
- Intercom or call station obstructed
- Access-controlled gate affecting an accessible route
- Entry sequence that does not work properly with assisted door operation
An existing access-control system does not automatically require complete replacement.
The opening should first be evaluated to determine whether the concern involves equipment placement, door hardware, system programming, operator sequencing or a broader building condition.
The appropriate corrective path depends on the actual opening and project requirements.
Coordination and Documentation
Accessibility-related decisions should be considered early rather than after the security equipment has already been installed.
Project coordination may involve:
- Property owner
- Facility manager
- Security integrator
- Door-hardware contractor
- Electrical contractor
- Automatic-door provider
- Architect or design professional
- Fire-alarm provider
- Authority having jurisdiction
NERSA’s role is to design and install the electronic security components so they can support the intended operation of the controlled opening.
Security-system design does not replace a project-specific accessibility, building-code or legal compliance determination where one is required.
Frequently Asked Questions
Does ADA accessibility affect access-control reader placement?
It can. Reader, keypad and intercom locations should be considered in relation to how an authorized user approaches and operates the controlled opening.
Can an automatic door operator work with access control?
Yes. When the equipment is compatible and properly coordinated, credential authorization, locking hardware and automatic door operation can work together as part of one controlled opening.
Can access control interfere with an accessible entrance?
Poorly selected or positioned equipment can make an opening more difficult to use. The complete door, hardware, credential device and approach should be considered during planning.
Does access control need to preserve emergency exit?
Yes. Electronic entry control should not improperly interfere with required egress or the designed life-safety operation of the opening.
Do accessibility considerations apply to pedestrian gates?
They may. When a controlled pedestrian gate is part of an accessible route, the gate, credential device, approach and operating arrangement should be evaluated together.
Can an existing access-controlled door be evaluated for accessibility concerns?
Yes. Existing equipment, door operation, reader placement, automatic operators and related access-control functions can be reviewed to determine what may need correction or additional coordination.
Does NERSA provide single-family home ADA access-control systems?
No. NERSA does not provide security installations for individual homes or single-family residences. We serve businesses, industrial and institutional facilities, and professionally managed apartment communities, including shared entrances, common areas, and grounds.
Request an Electronic Access Control Accessibility Assessment
Planning electronic access at an entrance, gate, or controlled opening requires attention to accessibility. NERSA can review equipment, door use, reader placement, automatic operator interaction, egress operation, and related requirements for your commercial or industrial property.
Whether the project involves one controlled entrance for a small business or coordinated access across a multi-building enterprise environment, accessibility should be considered as part of the complete controlled-opening design.
